1-Axis Headstock-Tailstock Welding Positioner

Product Description

Working Principle: The 1-Axis Headstock-Tailstock Welding Positioner is engineered to optimize the welding process by precisely manipulating heavy and complex workpieces. By securely fixing the workpiece to the worktable, the system rotates it to achieve the most accessible and required welding or assembly angle. This controlled rotation ensures consistent weld quality, reduces operator fatigue, and significantly enhances overall production efficiency for demanding industrial applications.

Electrical Control System (Supports Manual/Automatic/Linkage Modes):

Our advanced electrical control system is designed for maximum flexibility, supporting manual, fully automatic, and linkage operational modes to suit varying production requirements.

• Industrial Robot Integration: The positioner can be seamlessly controlled by an industrial robot to automatically adjust the welding angle, facilitating high-precision automated welding for complex trajectories.

• PLC Control: A reliable Programmable Logic Controller (PLC) governs the positioner's movements, ensuring stable operation during both automated sequences and manual welding tasks, providing operators with intuitive and precise control.

Customization Capabilities & Core Advantages:

Guansen Automation specializes in delivering tailored welding solutions. We professionally customize the positioner load capacity and physical dimensions according to your specific product characteristics and production needs, ensuring ideal welding speed and superior structural results. Every unit is constructed using high-quality steel and manufactured in our own factory through 13 rigorous processing steps to guarantee exceptional durability and product quality. All products undergo strict quality inspection protocols and have obtained relevant industry certifications.

Optional Components: To further enhance your production line, we offer optional integrations including industrial welding robot arms, dedicated welding machines, laser welding equipment, specialized welding torches, customized positioner color schemes, or structural modifications to incorporate a seventh-axis welding robot track. This automated welding solution offers low operational costs, professional-grade welding results, and is highly optimized for batch welding production.

Product Uses & Application Industries

This versatile 1-axis positioner is widely utilized across multiple heavy-duty manufacturing sectors to safely handle awkward or massive components.

• Pressure Vessel & Pipeline Industry: Ideal for rotating steel pipes, gas and water tanks, complex pipelines, and tower structures.

• Construction Machinery Industry: Perfectly suited for handling heavy excavator booms and arms, loader components, bulldozer parts, and other earthmoving equipment.

• Automotive Industry: Essential for manufacturing heavy and light truck chassis longitudinal beams, subframes, automotive chassis, frames, columns, beams, automotive battery box frames, and towing seats.

• Steel Structures: Facilitates the precise welding of H-beams, bridge steel components, heavy guide rails, and large flanges.

• Agricultural Machinery Parts: Used extensively for various parts of harvesters, tractors, storage silos, rotary tillers, and related farming equipment.

• Shipbuilding Industry: Streamlines the fabrication of shipping containers, massive ship hull parts, and marine components.

Product Operate Guide & After-Sales Support

We are committed to ensuring your team can operate the equipment safely and efficiently. Each positioner comes with comprehensive and professional instruction manuals. We provide one-on-one guidance from our dedicated technical engineers, along with robust support for online communication and remote training. For seamless integration into your facility, we support on-site commissioning and hands-on training. Additionally, free training and operational guidance are always available at the Guansen Automation factory.

FAQ

1. What data is needed for a customized welding solution or positioner?

To design the most effective solution, we require the workpiece weight, physical dimensions, welding material, weld thickness, and the desired welding effect or standard.

2. Can it be integrated with a welding robot?

Yes, integration is fully supported. The system is compatible with Modbus, Profinet, EtherCAT, and other standard communication protocols, allowing it to function seamlessly as a robot's external axis or seventh axis.

3. What are the installation, commissioning, and training services?

All equipment undergoes rigorous quality inspection and is only shipped after comprehensive commissioning is complete. We provide free personnel training. Alternatively, you can choose to have our expert engineers provide on-site installation, commissioning, and training until the equipment is operating normally in your facility.

4. What is the warranty?

We provide a comprehensive one-year warranty. Wear parts are provided free of charge during the warranty period (shipping costs are the buyer's responsibility).

5. What is the delivery time for the complete set of equipment?

Standard model: 7-15 days.

Customized model: 15-30 days (subject to final configuration confirmation).
